Fallout

Fallout is a puzzle game in which the player rotates rows of a grid to create vertical gaps that allow numbered tokens to fall through to the bottom. The grid is 17 columns wide by 9 rows deep, stored in the two-dimensional array h(17,9), with each row (bar) containing four randomly placed holes initialized at startup. Eight numbered tokens, represented as characters using CHR$ (z-52) to map values 101–108 to printable ASCII, are placed across the top row and must be dropped off the bottom edge to score points. Row rotation is implemented as a simple circular shift: left-rotation saves the leftmost cell, shifts all others one position left, and wraps the saved value to the rightmost position, while right-rotation does the reverse. After each rotation the gravity subroutine at line 2000 scans from the bottom upward, dropping any token that has an empty cell below it, and removes tokens that reach row 9 with no cell beneath them, incrementing the score. The game accepts a single INPUT string encoding the target row, direction, and number of repeated turns, allowing multi-step moves in one entry.

---

Program Structure

The program is organized into a main flow section and four subroutines:

Lines	Purpose
5–190	Initialization: dimension arrays, place bars with holes, place tokens
200–220	Initial display and gravity pass before first move
500–640	Main game loop: parse input, dispatch left/right rotation, apply gravity, redisplay
1000–1110	Display subroutine: prints entire grid with row labels
1500–1530	Cell rendering helper: blank, solid bar, or token character
2000–2150	Gravity subroutine: drops tokens downward, scores those reaching the bottom
3000–3050	Left-rotate a single row (circular shift left)
4000–4050	Right-rotate a single row (circular shift right)

Grid Representation

The grid is stored in h(17,9) where the first index is the column (1–17) and the second is the row (1–9). Cell values encode three states:

• 0 — empty (hole or cleared space)
• 1 — solid bar segment
• >100 — numbered token (values 101–108 for tokens 1–8)

Row 1 is the top “launch” row, rows 2–9 are the barrier rows. Each barrier row is initialized to all-solid (h(x,y)=1) and then four random columns are punched to zero, creating the holes through which tokens must eventually fall.

Token Encoding and Display

Tokens are stored as values 101–108. The display helper at line 1520 prints CHR$ (z-52); subtracting 52 from 101–108 yields ASCII codes 49–56, which are the characters 1 through 8. This is a compact encoding that avoids storing the display character separately. Solid bar cells are printed with PAPER 0 to produce a filled block appearance, while empty cells print a plain space.

Input Parsing

The INPUT at line 500 accepts a three-element string z$ (declared as DIM z$(3), so exactly three characters). The three characters are parsed positionally:

• z$(1) — bar number (1–8), converted to row index by adding 1 (since row 1 is reserved for tokens)
• z$(2) — direction: l for left, r for right
• z$(3) — number of rotation steps

Validation at lines 520–560 rejects out-of-range bar numbers, invalid step counts, and characters other than l or r. Multi-step rotation is handled by the loop at line 630, which decrements dx and re-dispatches the rotation subroutine until all steps are consumed — note this reuses d$ which is still set from the original input.

Rotation Subroutines

Left rotation (lines 3000–3050) saves h(1,y) into tm, shifts columns 1–16 left by one, then places tm at column 17 — a standard circular buffer shift. Right rotation (lines 4000–4050) is the mirror operation, saving h(17,y) and shifting columns 17 down to 2 rightward. Both operate on a single row y as determined by the parsed input.

Gravity and Scoring

The gravity subroutine (lines 2000–2150) iterates columns within rows, scanning from row 9 upward to row 1. When a token (h(x,c)>=100) is found, it attempts to drop it down through consecutive empty cells using a local variable ty. If ty reaches 9 and the cell below would be off the grid, the token is removed and sc is incremented. The game ends when sc=8 (all eight tokens scored), checked at line 620 with STOP.

Notable Techniques and Idioms

• The DIM z$(3) declaration constrains input to exactly three characters, combining type safety and length enforcement in a single statement.
• VAL z$(1) and VAL z$(3) convert single character positions of the string to numeric values without needing separate variables.
• The gravity loop uses GO TO 2040 to continue dropping a single token across multiple rows in one pass, rather than requiring repeated calls.
• The move counter br tracks total individual rotations applied across all inputs and is displayed as a “turns” score.

Bugs and Anomalies

• At line 120, INT (RND*16+1) generates values 1–16, not 1–17, so column 17 of each barrier row is never punched as a hole during initialization — it is always solid. This creates a systematic bias in the grid.
• The multi-step loop at line 630 re-evaluates d$ (still valid from line 530) and branches to line 570 or 580 via the same IF tests, but the GO TO 570 in line 630 skips the d$="r" check at line 580. If direction is r, line 630’s GO TO 570 will reach line 580’s check and work correctly since d$ is preserved — so this is functional but could be cleaner.
• The gravity subroutine’s inner drop loop condition at line 2040 checks ty>=9 to detect the bottom edge, but the grid’s last valid row index is 9, meaning a token sitting exactly on row 9 is immediately scored without checking whether a hole exists below — this is correct behavior since row 10 does not exist, but relies on the boundary condition rather than an explicit hole check.
