This file is part of CATS Library Tape 1, SINCUS Exchange Tape 101 - Entertainment, and Timex Sinclair Public Domain Library Tape 2004. Download the collection to get this file.
This program implements a two-player Tic-Tac-Toe game with a title screen, score tracking across multiple rounds, and a graphical board drawn using PLOT commands. The board grid lines are rendered pixel-by-pixel using PLOT in a FOR loop (lines 200–205), while X marks are drawn diagonally with PLOT offsets (subroutine at line 4000) and O marks use the built-in CIRCLE command (line 4054). Win detection works by storing player moves as values 1 (X) or 5 (O) in a 3×3 array s(), then checking whether any row, column, or diagonal sums to 3 or 15 respectively. A 10-element array t() tracks which cells are occupied to prevent overwriting, and cumulative scores in variables x and o are compared at the end of a session to declare an overall winner.
Program Analysis
Program Structure
The program divides into several clearly separated phases:
- Title screen (lines 15–70): draws a banner using block-graphic filled rectangles and a decorative pixel border via PLOT.
- Game initialization (lines 120–205): clears and sets up the game board, dimensions arrays, resets move counters.
- Turn selection & input loop (lines 220–279): prompts for who starts (X or O) and routes to the appropriate input handler.
- Move handlers (lines 1100–1960): one block per cell (1–9) for each player, setting array state, coordinates, and calling draw/win-check subroutines.
- Win/draw detection subroutines (lines 2900–2968): check all eight winning lines and the draw condition.
- Result screens (lines 2800–3130): announce X wins, O wins, or draw, update scores, and offer replay.
- Draw subroutines (lines 4000–4090): render X (diagonal PLOT), O (CIRCLE), and a victory fanfare (BEEP).
- Session summary (lines 5000–6010): compares cumulative scores and displays overall winner.
Board Representation
Two parallel data structures track game state. The array t(10) is a flat occupancy map: when a cell is taken, t(n) is set to 1, and any attempt to play there is rejected with a “TRY AGAIN” message (lines 3000–3028). The 2D array s(3,3) stores the player identity: X moves write 1, O moves write 5. This encoding is what makes the win-detection arithmetic work without needing separate checks per player.
Win Detection Technique
Rather than comparing values symbolically, the program exploits arithmetic sums. Three X’s in a line sum to 1+1+1 = 3; three O’s sum to 5+5+5 = 15. Subroutine 2900 checks all eight lines for a sum of 3 (X win) and subroutine 2950 checks for 15 (O win). This means both subroutines are structurally identical except for the target sum and the branch destination, allowing easy verification.
| Subroutine | Player | Cell value | Win sum | Calls on win |
|---|---|---|---|---|
2900 | X | 1 | 3 | GO TO 2800 |
2950 | O | 5 | 15 | GO TO 2850 |
The draw condition is checked in both subroutines at lines 2917 and 2967: q+z=9, where q counts X’s moves and z counts O’s moves.
Graphical Drawing Subroutines
The X marker (subroutine 4000) is drawn by plotting a center point then iterating j from 1 to 8, placing pixels at all four diagonal offsets (±j, ±j) relative to the coordinate pair (n, m). This produces two crossing diagonal lines of 8 pixels each. The O marker (subroutine 4050) simply calls CIRCLE n,m,10, making full use of the built-in graphics command. The grid itself is drawn by two nested PLOT loops at lines 200–205 that draw four lines of 161 pixels each at fixed pixel coordinates (52, 108 on each axis).
Move Handler Repetition
Lines 1100–1960 constitute the bulk of the listing. Each of the nine cells has two blocks — one for X (e.g., 1100–1110) and one for O (e.g., 1150–1160) — following an identical template:
- Check
t(n)=1; branch to occupied-cell handler if true. - Set
t(n)=1, sets(row,col)to 1 or 5. - Set pixel coordinates
nandm. GO SUB 4000(draw X) orGO SUB 4050(draw O).GO SUB 2900(check X win) orGO SUB 2950(check O win).- Branch to the other player’s input loop.
This highly repetitive pattern could have been condensed using a subroutine parameterized on the cell number, but the expanded form was common in BASIC programs of this era to avoid the overhead of additional subroutine calls and parameter-passing idioms.
Notable Techniques and Idioms
- INKEY$ polling without PAUSE: Input loops at lines 224–230, 244–259, and 264–279 use a bare
LET k$=INKEY$/LET w$=INKEY$followed by conditional branches, looping back on empty string. The singlePAUSE 0at line 70 (title screen) is a keypress wait rather than a polling loop. - Score persistence across games: Variables
xandoare initialized only at lines 20–25 (before the title screen) and are never reset during a “Play Again” restart (which returns to line 120, skipping lines 20–25). This correctly accumulates session totals. - Hidden debug/listing mode: Pressing
lat the end-of-game prompts (lines 2829, 2869, 3129) triggers aCLS/LIST/STOPsequence at lines 2880–2884, exposing the program listing for inspection without breaking out of the game loop directly. - Victory fanfare: Subroutine
4080plays a short ascending BEEP sequence (six notes) on any win; draws useINVERSE 1text only.
Bugs and Anomalies
- Stray
NEXT iat line 212: After the grid PLOT loop ends at line 205, line 212 contains an orphanedNEXT iwith no matching openFOR i. This will cause a “NEXT without FOR” error at runtime when the game board is first set up. The PLOT loop’s ownNEXT iis at line 205, so line 212 is clearly a leftover artifact. - Line 259 branches to 243, not 244: The fallback in the X input loop goes to line 243, which does not exist. The intent was clearly to branch back to line 244 (
LET w$=INKEY$). Because the target line does not exist, execution will fall through to line 244 anyway in most Sinclair BASIC implementations (which scan forward to the next available line), so this works accidentally. - Line 3129 branches to 1880: In the draw-game prompt, pressing
lbranches to line 1880, which is in the middle of the O move-handler for cell 8, rather than to the debug listing routine at line 2880. This appears to be a typo (missing leading digit). - Pixel coordinate system note: The TS2068 screen is 256×192 pixels, with the origin at the bottom-left. The cell center coordinates used (24, 80, 136 for x; 24, 80, 136 for y) place the grid in the lower portion of the display, consistent with the PLOT grid lines drawn at y=52 and y=108.
Content
Image Gallery
Source Code
5 REM tictactoe by R.W. Brown Adapted for 2068 by J. Colonna, SINCUS
10 REM Version 2.0
15 BORDER 6: CLS
20 LET x=0
25 LET o=0
45 PRINT AT 4,7;"\::\::\::\::\::\::\::\::\::\::\::\::\::"
50 PRINT AT 5,7;"\::TIC TAC TOE\::"
53 PRINT AT 6,7;"\::\::\::\::\::\::\::\::\::\::\::\::\::"
54 PRINT AT 10,15;"By";AT 12,17;"R. W. BROWN"
56 PRINT AT 14,22;"&"
58 PRINT AT 16,17;"J. COLONNA"
60 FOR i=1 TO 36
61 PLOT i,12: PLOT i,28: PLOT 12,i: PLOT 28,i
65 NEXT i
70 PRINT AT 19,8; FLASH 1;"Press any key to play.": PAUSE 0
120 CLS
122 DIM s(3,3)
124 DIM t(10)
126 LET q=0
128 LET z=0
130 PRINT AT 4,3;"1"
132 PRINT AT 4,10;"2"
134 PRINT AT 4,17;"3"
136 PRINT AT 11,3;"4"
138 PRINT AT 11,10;"5"
140 PRINT AT 11,17;"6"
142 PRINT AT 18,3;"7"
144 PRINT AT 18,10;"8"
146 PRINT AT 18,17;"9"
150 FOR l=1 TO 10
152 LET t(l)=0
154 NEXT l
160 FOR l=1 TO 3
161 FOR k=1 TO 3
162 LET s(l,k)=0
163 NEXT k
164 NEXT l
200 FOR i=0 TO 160
202 PLOT i,52: PLOT i,108: PLOT 52,i: PLOT 108,i
205 NEXT i
209 PRINT AT 1,24;"Score:"
212 NEXT i
214 PRINT AT 4,24;"X O"
216 PRINT AT 5,23;"---- ----"
218 PRINT AT 6,24;x;AT 6,29;o
220 PRINT AT 0,2; FLASH 1;"Who starts?"; FLASH 0;" X/O"
224 LET k$=INKEY$
226 IF k$="x" OR k$="X" THEN GO TO 240
228 IF k$="o" OR k$="O" THEN GO TO 260
230 GO TO 222
239 REM
240 PRINT AT 0,0;" "
242 PRINT AT 0,0;"X Where?";
244 LET w$=INKEY$
250 IF w$="1" THEN PRINT AT 4,3;" ": GO TO 1100
251 IF w$="2" THEN PRINT AT 4,10;" ": GO TO 1200
252 IF w$="3" THEN PRINT AT 4,17;" ": GO TO 1300
253 IF w$="4" THEN PRINT AT 11,3;" ": GO TO 1400
254 IF w$="5" THEN PRINT AT 11,10;" ": GO TO 1500
255 IF w$="6" THEN PRINT AT 11,17;" ": GO TO 1600
256 IF w$="7" THEN PRINT AT 18,3;" ": GO TO 1700
257 IF w$="8" THEN PRINT AT 18,10;" ": GO TO 1800
258 IF w$="9" THEN PRINT AT 18,17;" ": GO TO 1900
259 GO TO 243
260 PRINT AT 0,0;" "
262 PRINT AT 0,0;" O Where?";
264 LET w$=INKEY$
270 IF w$="1" THEN PRINT AT 4,3;" ": GO TO 1150
271 IF w$="2" THEN PRINT AT 4,10;" ": GO TO 1250
272 IF w$="3" THEN PRINT AT 4,17;" ": GO TO 1350
273 IF w$="4" THEN PRINT AT 11,3;" ": GO TO 1450
274 IF w$="5" THEN PRINT AT 11,10;" ": GO TO 1550
275 IF w$="6" THEN PRINT AT 11,17;" ": GO TO 1650
276 IF w$="7" THEN PRINT AT 18,3;" ": GO TO 1750
277 IF w$="8" THEN PRINT AT 18,10;" ": GO TO 1850
278 IF w$="9" THEN PRINT AT 18,17;" ": GO TO 1950
279 GO TO 263
1099 REM
1100 IF t(1)=1 THEN GO TO 3000
1102 LET t(1)=1
1104 LET s(1,1)=1
1105 LET n=24
1106 LET m=136
1107 GO SUB 4000
1108 GO SUB 2900
1110 GO TO 260
1150 IF t(1)=1 THEN GO TO 3020
1152 LET t(1)=1
1154 LET s(1,1)=5
1155 LET n=24
1156 LET m=136
1157 GO SUB 4050
1158 GO SUB 2950
1160 GO TO 240
1200 IF t(2)=1 THEN GO TO 3000
1202 LET t(2)=1
1204 LET s(1,2)=1
1205 LET n=80
1206 LET m=136
1207 GO SUB 4000
1208 GO SUB 2900
1210 GO TO 260
1250 IF t(2)=1 THEN GO TO 3020
1252 LET t(2)=1
1254 LET s(1,2)=5
1255 LET n=80
1256 LET m=136
1257 GO SUB 4050
1258 GO SUB 2950
1260 GO TO 240
1300 IF t(3)=1 THEN GO TO 3000
1302 LET t(3)=1
1304 LET s(1,3)=1
1305 LET n=136
1306 LET m=136
1307 GO SUB 4000
1308 GO SUB 2900
1310 GO TO 260
1350 IF t(3)=1 THEN GO TO 3020
1352 LET t(3)=1
1354 LET s(1,3)=5
1355 LET n=136
1356 LET m=136
1357 GO SUB 4050
1358 GO SUB 2950
1360 GO TO 240
1400 IF t(4)=1 THEN GO TO 3000
1402 LET t(4)=1
1404 LET s(2,1)=1
1405 LET n=24
1406 LET m=80
1407 GO SUB 4000
1408 GO SUB 2900
1410 GO TO 260
1450 IF t(4)=1 THEN GO TO 3020
1452 LET t(4)=1
1454 LET s(2,1)=5
1455 LET n=24
1456 LET m=80
1457 GO SUB 4050
1458 GO SUB 2950
1460 GO TO 240
1500 IF t(5)=1 THEN GO TO 3000
1502 LET t(5)=1
1504 LET s(2,2)=1
1505 LET n=80
1506 LET m=80
1507 GO SUB 4000
1508 GO SUB 2900
1510 GO TO 260
1550 IF t(5)=1 THEN GO TO 3020
1552 LET t(5)=1
1554 LET s(2,2)=5
1555 LET n=80
1556 LET m=80
1557 GO SUB 4050
1558 GO SUB 2950
1560 GO TO 240
1600 IF t(6)=1 THEN GO TO 3000
1602 LET t(6)=1
1604 LET s(2,3)=1
1605 LET n=136
1606 LET m=80
1607 GO SUB 4000
1608 GO SUB 2900
1610 GO TO 260
1650 IF t(6)=1 THEN GO TO 3020
1652 LET t(6)=1
1654 LET s(2,3)=5
1655 LET n=136
1656 LET m=80
1657 GO SUB 4050
1658 GO SUB 2950
1660 GO TO 240
1700 IF t(7)=1 THEN GO TO 3000
1702 LET t(7)=1
1704 LET s(3,1)=1
1705 LET n=24
1706 LET m=24
1707 GO SUB 4000
1708 GO SUB 2900
1710 GO TO 260
1750 IF t(7)=1 THEN GO TO 3020
1752 LET t(7)=1
1754 LET s(3,1)=5
1755 LET n=24
1756 LET m=24
1757 GO SUB 4050
1758 GO SUB 2950
1760 GO TO 240
1800 IF t(8)=1 THEN GO TO 3000
1802 LET t(8)=1
1804 LET s(3,2)=1
1805 LET n=80
1806 LET m=24
1807 GO SUB 4000
1808 GO SUB 2900
1810 GO TO 260
1850 IF t(8)=1 THEN GO TO 3020
1852 LET t(8)=1
1854 LET s(3,2)=5
1855 LET n=80
1856 LET m=24
1857 GO SUB 4050
1858 GO SUB 2950
1860 GO TO 240
1900 IF t(9)=1 THEN GO TO 3000
1902 LET t(9)=1
1904 LET s(3,3)=1
1905 LET n=136
1906 LET m=24
1907 GO SUB 4000
1908 GO SUB 2900
1910 GO TO 260
1950 IF t(9)=1 THEN GO TO 3020
1952 LET t(9)=1
1954 LET s(3,3)=5
1955 LET n=136
1956 LET m=24
1957 GO SUB 4050
1958 GO SUB 2950
1960 GO TO 240
2800 PRINT AT 0,0;" "
2801 LET x=x+1
2802 PRINT AT 0,2; FLASH 1;" X WINS...": GO SUB 4080
2804 PRINT AT 1,0;"Play Again? Y/N"
2805 PRINT AT 6,24;x;AT 6,29;o
2808 LET s$=INKEY$
2827 IF s$="n" OR s$="N" THEN GO TO 5000
2828 IF s$="y" OR s$="Y" THEN GO TO 120
2829 IF s$="l" THEN GO TO 2880
2830 GO TO 2808
2850 PRINT AT 0,0;" "
2851 LET o=o+1
2852 PRINT AT 0,2; FLASH 1;" O WINS...": GO SUB 4080
2854 PRINT AT 1,0;"Play Again? Y/N"
2855 PRINT AT 6,24;x;AT 6,29;o
2858 LET s$=INKEY$
2867 IF s$="n" OR s$="N" THEN GO TO 5000
2868 IF s$="y" OR s$="Y" THEN GO TO 120
2869 IF s$="l" THEN GO TO 2880
2870 GO TO 2858
2880 CLS
2882 LIST
2884 STOP
2889 REM
2900 LET q=q+1
2902 IF s(1,1)+s(1,2)+s(1,3)=3 THEN GO TO 2800
2904 IF s(2,1)+s(2,2)+s(2,3)=3 THEN GO TO 2800
2906 IF s(3,1)+s(3,2)+s(3,3)=3 THEN GO TO 2800
2908 IF s(1,1)+s(2,1)+s(3,1)=3 THEN GO TO 2800
2910 IF s(1,2)+s(2,2)+s(3,2)=3 THEN GO TO 2800
2912 IF s(1,3)+s(2,3)+s(3,3)=3 THEN GO TO 2800
2914 IF s(1,1)+s(2,2)+s(3,3)=3 THEN GO TO 2800
2916 IF s(1,3)+s(2,2)+s(3,1)=3 THEN GO TO 2800
2917 IF q+z=9 THEN GO TO 3100
2918 RETURN
2949 REM
2950 LET z=z+1
2952 IF s(1,1)+s(1,2)+s(1,3)=15 THEN GO TO 2850
2954 IF s(2,1)+s(2,2)+s(2,3)=15 THEN GO TO 2850
2956 IF s(3,1)+s(3,2)+s(3,3)=15 THEN GO TO 2850
2958 IF s(1,1)+s(2,1)+s(3,1)=15 THEN GO TO 2850
2960 IF s(1,2)+s(2,2)+s(3,2)=15 THEN GO TO 2850
2962 IF s(1,3)+s(2,3)+s(3,3)=15 THEN GO TO 2850
2964 IF s(1,1)+s(2,2)+s(3,3)=15 THEN GO TO 2850
2966 IF s(1,3)+s(2,2)+s(3,1)=15 THEN GO TO 2850
2967 IF q+z=9 THEN GO TO 3100
2968 RETURN
3000 PRINT AT 0,0;" "
3002 PRINT AT 0,0;"TRY AGAIN"
3004 PAUSE 400
3008 GO TO 240
3020 PRINT AT 0,0;" "
3022 PRINT AT 0,0;"TRY AGAIN"
3024 PAUSE 400
3028 GO TO 260
3100 PRINT AT 0,0;" "
3102 PRINT AT 0,1; INVERSE 1;"No One Won,,,"
3104 PRINT AT 1,0;"Play Again? Y/N"
3108 LET s$=INKEY$
3127 IF s$="n" OR s$="N" THEN GO TO 5000
3128 IF s$="y" OR s$="Y" THEN GO TO 120
3129 IF s$="l" THEN GO TO 1880
3130 GO TO 3108
4000 REM X
4001 PLOT n,m
4002 FOR j=1 TO 8
4004 PLOT n+j,m+j
4006 PLOT n+j,m-j
4008 PLOT n-j,m+j
4010 PLOT n-j,m-j
4012 NEXT j
4014 RETURN
4050 REM circle
4054 CIRCLE n,m,10
4070 RETURN
4080 BEEP .15,0: BEEP .15,4: BEEP .15,7: BEEP .25,12: BEEP .15,9: BEEP .3,12
4090 RETURN
5000 CLS
5002 IF x>o THEN GO TO 5020
5004 IF x<o THEN GO TO 5040
5006 IF x=o THEN GO TO 5060
5020 PRINT AT 5,10;"X WINS"
5022 PRINT AT 6,9;"========="
5024 PRINT AT 12,4;"X=";x
5026 PRINT AT 14,4;"O=";o
5028 GO TO 6000
5040 PRINT AT 5,10;"O WINS"
5042 PRINT AT 6,9;"========="
5044 PRINT AT 12,4;"O=";o
5046 PRINT AT 14,4;"X=";x
5048 GO TO 6000
5060 PRINT AT 5,10;"TIE TIE TIE"
5062 PRINT AT 6,9;"==============="
5064 PRINT AT 12,4;"X/O=";x
5066 PRINT AT 16,2; INVERSE 1;"TRY HARDER NEXT TIME..."
5068 GO TO 6000
6000 PAUSE 1000
6010 STOP
9999 SAVE "tictactoe" LINE 1: BEEP 1,32Note: Type-in program listings on this website use ZMAKEBAS notation for graphics characters.
