VOCABUILDER 1000 Version 2.0 is a two-language vocabulary flashcard and testing program. It stores up to 100 word-pairs in a two-dimensional string array A$(2, W+1, 32), supporting add, edit, insert, and delete operations via a full-screen editor, plus two randomised test modes (random-only and random with language interchange). The program uses FAST/SLOW switching throughout to maximise display speed during computation and restore keyboard responsiveness for input. Results can be sent to a printer via LPRINT, and the vocabulary file is saved to tape with a deliberate PAUSE 420 leader-compensation delay before the SAVE command.
Program Structure
The program is divided into clearly separated modules, each residing at a round-number line block, dispatched from the main menu via the idiom GOTO A*1000 at line 250:
| Line block | Function |
|---|---|
| 90–250 | Initialisation and main menu |
| 1000–1710 | Edit / Add / Insert / Delete file viewer |
| 2000–2660 | Practice mode (menu option 2) |
| 3000–3530 | Test 1 – Random only; shared report subroutine |
| 4000–4050 | Test 2 – Random + Interchange |
| 5000–5120 | New file setup |
| 6000–6210 | Printer output |
| 7000–7200 | Save to tape |
| 9998–9999 | Bootstrap: saves program then re-runs from line 95 |
Lines 95 and 97 set the working constants W=100 (maximum slots) and N=1 (next free slot). Line 90 jumps over these so that a plain RUN preserves previously loaded data; line 9999 uses RUN 95 after the bootstrap save so defaults are always initialised fresh.
Data Model
All vocabulary is held in the three-dimensional string array A$(2, W+1, 32), dimensioned at line 5090. The first dimension selects the language (1 or 2), the second selects the word-pair slot, and the third is the 32-character string length. Language names are stored in N$(2, N) where N is computed as the length of the longer name, capped at 16 characters.
A parallel two-dimensional array B$(2, E) is used during tests to track per-slot state: a space character means untested/wrong (needs re-attempt), "1" means correctly answered in practice mode, and "X" records a wrong answer in test modes for the report.
Menu Dispatch and Input Validation
The main menu dispatch at line 250 uses GOTO A*1000, where A = VAL Y$. This is an elegant computed GOTO that requires no IF chain. Input validation at lines 220–225 prevents illegal choices and also blocks options 2–4 and 6 when fewer than two entries exist (N<2), since practice and testing are meaningless on an empty file.
Editor Navigation
The file editor at line 1000 displays five entries at a time (controlled by Y=5 at line 1040). Navigation commands entered as strings are parsed by their first character Z$=Y$(1):
C– Continue: advance by one slotB– Back: retreat by 9 slots (net −10 then +1 on next display)Snnn – Start from slot nnnInnn – Insert before slot nnn (shifts entries up)Dnnn – Delete slot nnn (shifts entries down)Ennn – Edit slot nnnA– Add at the end (next free slot)
Insert (lines 1310–1370) loops from N+1 down to the target slot+1 with STEP -1, copying each entry one place up — a correct in-place array shift. Delete (lines 1400–1470) loops forward, shifting entries down.
Test and Practice Logic
Practice mode (option 2) and Test 1 (option 3) share a GOSUB-based structure. The practice subroutine begins at line 2160 (screen clear and random pick) and is called from both 3050 and the practice main loop. The variable A (the original menu choice, 2, 3, or 4) is tested inside the subroutine at lines 2272 and 2300 to determine whether to branch back to the report or return to the caller — a non-obvious coupling between the subroutine and calling context.
Test 2 (option 4) selects a random language each round (L=INT(RND*2)+1) and after 10 consecutive failed attempts to find an untested slot (Z>10 at line 2203), switches to a sequential scan of remaining slots (lines 2600–2660).
FAST/SLOW Switching
The program switches to FAST mode before computation-heavy or display-heavy sections and returns to SLOW before every INPUT statement. This pattern appears at least a dozen times (e.g. lines 100, 205, 215, 1003, 1069, 1075, 2025, 2125, 2255, 2270) and is idiomatic for maximising display performance while keeping keyboard scanning reliable.
Tape Save Sequence
The save routine at line 7000 includes a PAUSE 420 (approximately 7 seconds at line 7087) before the SAVE command, explicitly described in the on-screen instructions as automatic tape-leader compensation. The variable array G$ is redimensioned to DIM G$(1) at line 7005 before saving, discarding any temporary quiz data that should not be persisted. The bootstrap block at lines 9998–9999 saves the program itself under the name "VOCAB 1000" (the %0 renders as the digit 0 via the inverse-character idiom) then restarts cleanly.
Notable Techniques and Idioms
NOT PIevaluates to 0 (since PI is non-zero, NOT returns 0), used as a portable zero constant in severalATandPRINTexpressions (lines4020,5040,6011, etc.).NOT (L-1)toggles between 0 and 1, used to select the opposite language index (lines2210,2220,2630).- Score calculation at line
3470uses the boolean expressions(A=3)and(2 AND A=4)to compute a multiplier of 1 for Test 1 or 2 for Test 2, avoiding anIFbranch. - The print format
"%S%L%O%T%S"uses inverse-video characters (the%prefix renders each following letter in inverse) to produce highlighted text in the menu header. LET S=PI/PIat line1000is an unnecessarily indirect way to setS=1, possibly written this way for novelty or to avoid a literal1.
Content
Image Gallery
Source Code
90 GOTO 100
95 LET W=100
97 LET N=1
100 FAST
101 DIM B$(1)
102 DIM G$(32)
103 LET Q=0
104 LET F=Q
105 CLS
110 PRINT ":'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''':: VOCABUILDER 1000 VERSION 2.0 ::..............................................................:"
115 PRINT ,,"%S%L%O%T%S% %U%S%E%D ";N-1,"%S%L%O%T%S% %L%E%F%T ";W-N+1
120 PRINT AT 7,11;"**% %M%E%N%U% **"
130 PRINT AT 9,0;"<1> EDIT / ADD / CHECK FILE"
140 PRINT "<2> PRACTICE VOCABULARIES"
150 PRINT "<3> TEST 1--RANDOM ONLY"
160 PRINT "<4> TEST 2--RANDOM + INTERCHANGE"
170 PRINT "<5> SETUP NEW FILE"
180 PRINT "<6> HARD COPY--PRINTER OUTPUT"
190 PRINT "<7> SAVE ON TAPE"
200 PRINT AT 20,0;" INPUT YOUR CHOICE BY NUMBER ?",," ''''''''''''''''''"
205 SLOW
210 INPUT Y$
215 FAST
220 IF Y$="" OR Y$<"1" OR Y$>"7" THEN GOTO 205
225 IF VAL Y$>7 OR Y$<>"1" AND Y$<>"5" AND Y$<>"7" AND N<2 THEN GOTO 205
230 CLS
240 LET A=VAL Y$
250 GOTO A*1000
1000 LET S=PI/PI
1003 FAST
1004 LET Y=1
1005 FOR Z=S TO N
1010 PRINT "% %N%U%M%B%E%R% ";Z;"---"
1020 PRINT A$(1,Z)
1030 PRINT A$(2,Z)
1040 IF Y=5 THEN GOTO 1060
1045 LET Y=Y+1
1050 NEXT Z
1060 PRINT AT 16,0;"% % E%D%I%T% % % A%D%D% % % I%N%S%E%R%T% % % D%E%L%E%T%E% % % % C%O%N%T%I%N%U%E% % % B%A%C%K% % % S%T%A%R%T% %F%R%O%M% % "
1065 IF N>W THEN PRINT ,,,,,,"% %F%I%L%E% %F%U%L%L% "
1069 SLOW
1070 INPUT Y$
1075 FAST
1080 IF Y$="" THEN GOTO 100
1090 LET Z$=Y$(1)
1100 IF Z$="B" OR Z$="C" OR Z$="S" THEN GOTO 1200
1110 IF Z$="I" OR Z$="D" THEN GOTO 1300
1120 IF Z$="E" OR Z$="A" THEN GOTO 1500
1130 GOTO 1069
1200 IF Z$="C" THEN LET Z=Z+1
1210 IF Z$="B" THEN LET Z=Z-9
1215 IF Z$="S" AND LEN Y$=1 THEN GOTO 1069
1220 IF Z$="S" THEN LET Z=VAL Y$(2 TO )
1230 IF Z>N THEN LET Z=N-4
1240 IF Z<1 THEN LET Z=1
1245 LET S=Z
1250 CLS
1260 GOTO 1004
1300 IF LEN Y$=1 THEN GOTO 1069
1302 IF VAL Y$(2 TO )>=N OR VAL Y$(2 TO )<1 THEN GOTO 1069
1305 IF Z$="D" THEN GOTO 1400
1307 IF N>W THEN GOTO 1069
1310 FOR Q=N+1 TO VAL Y$(2 TO )+1 STEP -1
1320 LET A$(1,Q)=A$(1,Q-1)
1330 LET A$(2,Q)=A$(2,Q-1)
1340 NEXT Q
1350 LET Z$="E"
1360 LET N=N+1
1370 GOTO 1510
1400 FOR Q=VAL Y$(2 TO ) TO N
1410 LET A$(1,Q)=A$(1,Q+1)
1420 LET A$(2,Q)=A$(2,Q+1)
1430 NEXT Q
1440 IF N>1 THEN LET N=N-1
1450 LET S=VAL Y$(2 TO )-2
1455 IF S+4>N THEN LET S=N-4
1457 IF S<1 THEN LET S=1
1460 CLS
1470 GOTO 1003
1500 IF Z$="E" AND LEN Y$=1 THEN GOTO 1069
1510 IF Z$="E" THEN LET E=VAL Y$(2 TO )
1512 IF Z$="E" THEN IF E>N-1 THEN GOTO 1069
1515 IF Z$="A" AND N>W THEN GOTO 1069
1520 IF Z$="A" THEN LET E=N
1525 PRINT AT 16,0;"% % N%E%X%T% % % % % ""ENTER""% %T%O% %T%E%R%M%I%N%A%T%E% % % % % % % % % % % % %W%H%E%N% %"%>%"% %I%S% %S%H%O%W%I%N%G% % "
1530 PRINT AT 19,0;"% %N%U%M%B%E%R% ";E;TAB 14;"?>";N$(1)
1540 INPUT Y$
1545 IF Y$="N" THEN GOTO 1580
1550 IF Y$="" THEN GOTO 1700
1560 LET A$(1,E)=Y$
1570 PRINT A$(1,E)
1580 PRINT AT 19,15;" ";N$(2)
1590 INPUT Y$
1600 IF Y$="" OR Y$="N" THEN GOTO 1530
1610 LET A$(2,E)=Y$
1700 LET Y$=Z$+STR$ E
1705 IF Z$="A" THEN LET N=N+1
1710 GOTO 1450
2000 PRINT "***********% %P%R%A%C%T%I%C%E% ***********"
2010 PRINT AT 3,0;" INPUT LANGUAGE TO BE TESTED ? (BY NUMBER)"
2020 PRINT ,,"<1> ";N$(1);TAB 0;"<2> ";N$(2)
2022 PRINT AT 21,0;" INPUT ""0"" TO TERMINATE"
2025 SLOW
2030 INPUT L
2035 IF L<1 THEN GOTO 100
2040 IF L>2 THEN GOTO 2030
2050 PRINT AT 3,30;L
2060 PRINT AT 11,0;" INPUT STARTING NUMBER ? ";
2070 INPUT S
2080 IF S<1 THEN GOTO 100
2090 IF S>=N THEN LET S=N-1
2095 IF S<1 THEN LET S=1
2100 PRINT S
2110 PRINT ,," INPUT ENDING NUMBER ? "
2120 INPUT E
2125 FAST
2130 IF E<1 THEN GOTO 100
2135 IF E<S THEN LET E=S
2140 IF E>=N THEN LET E=N-1
2150 DIM B$(2,E)
2170 CLS
2195 LET Z=0
2200 LET R=INT (RND*(E-S+1))+S
2202 LET Z=Z+1
2203 IF A=4 AND Z>10 THEN GOTO 2600
2205 IF B$(L,R)<>" " THEN GOTO 2200
2207 LET B$(L,R)="1"
2210 PRINT "** ";N$(1+NOT (L-1))
2220 PRINT ,,A$(1+NOT (L-1),R)
2245 PRINT AT 20,3;"% %I%N%P%U%T% %S%H%I%F%T% %"%Q%"% %T%O% %Q%U%I%T% "
2250 PRINT AT 6,0;"PLEASE INPUT ";N$(L);" ?"
2252 PRINT TAB 13;"''''''''''''''''''''''''''''''''"( TO LEN N$(1))
2255 SLOW
2260 INPUT G$
2270 FAST
2272 IF G$(1)="""" THEN GOTO (2380 AND A=2)+(3070 AND A>2)
2275 IF F=0 THEN PRINT G$
2280 LET F=0
2290 IF G$<>A$(L,R) THEN LET F=1
2300 IF A=3 OR A=4 THEN RETURN
2310 IF F=0 THEN GOTO 2360
2320 PRINT AT 10,10;"**% %W%R%O%N%G% **",,," THE CORRECT ANSWER IS..."
2330 PRINT ,,A$(L,R)
2340 PRINT ,,,,,,"PLEASE INPUT THE CORRECT ANSWER?''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''"
2345 LET B$(L,R)=" "
2350 GOTO 2255
2360 LET Q=Q+1
2365 IF B$(L,R)=" " THEN LET Q=Q-1
2370 IF Q<=E-S THEN GOTO 2160
2380 CLS
2390 PRINT AT 10,11;"% %F%I%N%I%S%H%E%D% "
2400 SLOW
2500 PAUSE 180
2510 GOTO 100
2600 FOR Z=S TO E
2610 IF B$(L,Z)=" " THEN GOTO 2650
2620 NEXT Z
2630 LET L=1+NOT (L-1)
2640 GOTO 2180
2650 LET R=Z
2660 GOTO 2207
3000 PRINT "************% %T%E%S%T% %1% ************"
3010 GOSUB 2010
3025 IF F=1 THEN LET B$(L,R)="X"
3030 LET Q=Q+1
3035 IF Q=(E-S+1)*(1+(A=4)) THEN GOTO 3070
3040 IF A=4 THEN LET L=INT (RND*2)+1
3050 GOSUB 2160
3060 GOTO 3020
3070 CLS
3080 PRINT "*********% %T%E%S%T% %R%E%P%O%R%T% **********"
3085 PRINT AT 3,11;"% %O%P%T%I%O%N%S% "
3090 PRINT ,,,,"<1> OUTPUT MISSED WORDS"
3100 PRINT "<2> OPTION <1> + PRINTER OUTPUT"
3110 PRINT "<3> SCORE REPORT--ONLY WHEN THE TEST WAS COMPLETED."
3120 PRINT "<4> RETURN TO MENU"
3130 PRINT AT 20,0;" INPUT YOUR CHOICE BY NUMBER ?",," ''''''''''''''''''"
3140 SLOW
3150 INPUT Q
3160 FAST
3170 IF Q<1 OR Q>4 OR Q=3 AND G$(1)="""" THEN GOTO 3140
3175 CLS
3180 IF Q=4 THEN GOTO 100
3190 IF Q=3 THEN GOTO 3400
3210 LET Y=1
3220 FOR Z=S TO E
3230 IF B$(1,Z)<>"X" AND B$(2,Z)<>"X" THEN GOTO 3290
3240 PRINT "% %N%U%M%B%E%R% ";Z;"---"
3250 PRINT A$(1,Z);A$(2,Z)
3260 IF Q=2 THEN LPRINT A$(1,Z);A$(2,Z),,
3270 IF Y=7 THEN GOTO 3300
3280 LET Y=Y+1
3290 NEXT Z
3300 POKE 16418,0
3310 PRINT AT 23,0;"PRESS ANY KEY TO CONTINUE"
3320 POKE 16418,2
3330 SLOW
3340 IF INKEY$="" THEN GOTO 3340
3345 FAST
3347 CLS
3350 IF Z>=E THEN GOTO 3070
3360 LET Y=1
3370 GOTO 3290
3400 LET Q=0
3410 FOR Z=S TO E
3420 IF B$(1,Z)="X" THEN LET Q=Q+1
3425 IF B$(2,Z)="X" THEN LET Q=Q+1
3430 NEXT Z
3440 PRINT "% %W%O%R%D%S% %T%E%S%T%E%D% ";(E-S+1)*((A=3)+(2 AND A=4))
3450 PRINT ,,"% %C%O%R%R%E%C%T% %A%N%S%W%E%R%S% ";(E-S+1)*((A=3)+(2 AND A=4))-Q
3460 PRINT ,,"% %W%R%O%N%G% %A%N%S%W%E%R%S% ";Q
3470 LET Z=INT ((1-Q/(E-S+1)/((A=3)+(2 AND A=4)))*100+.5)
3480 PRINT ,,,,"% %S%C%O%R%E% ";Z;" PERCENT"
3490 PRINT AT 20,0;"PRESS ANY KEY TO CONTINUE"
3500 SLOW
3510 IF INKEY$="" THEN GOTO 3510
3520 FAST
3530 GOTO 3070
4000 PRINT "************% %T%E%S%T% %2% ************"
4005 PRINT AT 4,6;"INTERCHANGE BETWEEN"
4007 PRINT AT 6,9;"TWO LANGUAGES"
4010 LET L=INT (RND*2)+1
4020 PRINT AT 21,NOT PI;" INPUT ""0"" TO TERMINATE"
4030 SLOW
4040 GOSUB 2060
4050 GOTO 3020
5000 PRINT "********% %N%E%W% %F%I%L%E% %S%E%T%U%P% ********";AT 20,0;"PRESS ""ENTER"" TO TERMINATE"
5010 PRINT AT 3,0;" INPUT FIRST LANGUAGE ?",
5015 SLOW
5020 INPUT Y$
5030 IF Y$="" THEN GOTO 100
5035 PRINT Y$
5040 PRINT AT 7,NOT PI;" INPUT SECOND LANGUAGE ?"
5050 INPUT Z$
5055 FAST
5060 IF Z$="" THEN GOTO 100
5070 LET N=(LEN Y$ AND LEN Y$>=LEN Z$)+(LEN Z$ AND LEN Z$>LEN Y$)
5075 IF N>16 THEN LET N=16
5080 DIM N$(2,N)
5083 LET N$(1)=Y$
5086 LET N$(2)=Z$
5090 DIM A$(2,W+1,32)
5100 LET N=1
5110 CLS
5120 GOTO 1000
6000 PRINT "********% %P%R%I%N%T%E%R% %O%U%T%P%U%T% ********"
6010 PRINT AT 3,NOT PI;" INPUT SELECTION ?","<1> ";N$(1);TAB 0;"<2> ";N$(2);TAB 0;"<3> BOTH"
6011 PRINT AT 21,NOT PI;" INPUT ""0"" TO TERMINATE MODE"
6012 SLOW
6013 INPUT Z
6014 IF Z<1 THEN GOTO 100
6015 IF Z>3 THEN GOTO 6012
6016 PRINT AT 3,18;Z
6017 PRINT AT 8,0;"SPACE BETWEEN EACH GROUP ? ";
6018 LET Z$=INKEY$
6019 IF Z$="" THEN GOTO 6018
6020 IF Z$="0" THEN GOTO 100
6021 IF Z$<>"Y" THEN LET Z$="N"
6022 PRINT Z$
6025 PRINT AT 12,0;" INPUT STARTING NUMBER ? ";
6030 INPUT S
6040 IF S<1 THEN GOTO 100
6050 IF S>N THEN GOTO 6030
6060 PRINT S
6070 PRINT AT 14,0;" INPUT ENDING NUMBER ? ";
6080 INPUT E
6090 IF E<1 THEN GOTO 100
6100 IF E<S THEN GOTO 6080
6105 IF E>N THEN LET E=N-1
6110 PRINT E
6120 PRINT AT 20,0;"PRESS ANY KEY TO PRINT OR "
6130 LET Y$=INKEY$
6140 IF Y$="" THEN GOTO 6130
6150 IF Y$="0" THEN GOTO 100
6155 FAST
6160 FOR Q=S TO E
6170 IF Z=1 OR Z=3 THEN LPRINT A$(1,Q)
6180 IF Z=2 OR Z=3 THEN LPRINT A$(2,Q)
6185 IF Z$="Y" THEN LPRINT
6190 NEXT Q
6200 SLOW
6210 GOTO 100
7000 PRINT "*************% %S%A%V%E% *************"
7005 DIM G$(1)
7010 PRINT AT 5,0;"<1> PREPARE RECORDER FOR ""SAVE"""
7020 PRINT "<2> REWIND TAPE"
7030 PRINT "<3> PRESS ""RECORD"" AND ""PLAY"""
7040 PRINT "<4> PRESS ANY KEY TO SAVE "," (TAPE LEADER IS"," AUTOMATICALLY COMPENSATED)"
7050 PRINT AT 21,5;"PRESS ""0"" TO TERMINATE"
7055 SLOW
7057 IF INKEY$<>"" THEN GOTO 7057
7060 LET Y$=INKEY$
7070 IF Y$="" THEN GOTO 7060
7080 IF Y$="0" THEN GOTO 100
7083 PRINT AT 15,10;"% %P%R%O%C%E%S%S%I%N%G% "
7085 PRINT AT 21,0;" "
7087 PAUSE 420
7088 FAST
7090 CLS
7100 SAVE "%V"
7110 PRINT "*******% %V%O%C%A%B%U%I%L%D%E%R% %1%0%0%0% *******"
7120 PRINT AT 6,11;"WRITTEN BY";AT 11,8;":'''''''''''''''''''''''''''''':";TAB 8;": CHIA-CHI CHAO :";TAB 8;":..............................:"
7135 SLOW
7140 FOR Q=1 TO 30
7150 NEXT Q
7200 GOTO 100
9998 SAVE "VOCAB 100%0"
9999 RUN 95
Note: Type-in program listings on this website use ZMAKEBAS notation for graphics characters.
